The RV Cable is a premium-grade single-core copper conductor wire insulated with flexible PVC, designed for dependable electrical connections across various environments. Produced by Zhejiang Zhongjing Wire & Cable Co., Ltd, this cable offers exceptional bending performance, stable conductivity, and long service life, making it a trusted choice for both industrial and domestic applications.
Product Specifications
|
RV Cable |
High-Performance Flexible PVC Insulated Wire |
|
Conductor |
Class 5 stranded copper (0.2mm strands) |
|
Insulation layer |
PVC (70°C operational) |
|
Inner layer |
Stranded Copper |
|
Outer layer |
PVC |
|
Feature |
RV (Single-core) |
|
Sheath |
No |
|
EMI Protection |
None |
|
Flexibility |
Highest |
|
Best For |
Internal wiring |
|
Manufacturer |
Zhejiang Zhongjing Wire & Cable Co., Ltd |
Advantages
Exceptional Flexibility: The fine-stranded copper core allows the cable to bend, twist, and coil tightly without kinking or breaking. This makes it ideal for devices requiring movement (e.g., small appliances, tools) or installation in narrow spaces (e.g., control cabinets, machinery).
High Conductivity: The high-purity copper strands ensure efficient power/signal transmission with minimal energy loss, comparable to solid-core cables.
Durability in Dynamic Use: Resists fatigue from repeated bending, extending service life in applications with frequent movement (e.g., robot arms, portable equipment).
Compact and Lightweight: The thin PVC insulation and stranded design result in a slim, lightweight cable, easy to route through tight gaps or bundle with other wires.
Cost-Effective: Balances performance and affordability, making it a practical choice for both industrial and household flexible wiring needs.
Broad Environmental Adaptability: Withstands low temperatures (-30°C) and mild chemicals, performing reliably in diverse settings from home appliances to factory control systems.
Customization Options
At Zhejiang Zhongjing Wire & Cable Co., Ltd, we provide flexible customization for RV Cables to meet specific market and project demands:
- Conductor size and strand configuration
- Special PVC compound for enhanced heat or UV resistance
- Color-coded insulation for easier circuit identification
- Customized coil or reel lengths
- OEM printing with customer logo or technical markings
Product Application
Industrial Distribution: It is widely used in industrial distribution fields, especially in flexible installation places with strict requirements, such as electrical control cabinets, distribution boxes and various low - voltage electrical equipment. It can be used for the transmission of power, electrical control signals and switch signals.
Household Appliances: It is also suitable for connecting household appliances such as TVs, computers and stereos, and can meet the power connection needs of general household electrical equipment.
Technical Data
|
Item Spec |
Nominal Section |
No./Dia.of Conductor |
Insulation Thickness |
Overal Diameter |
|
H05V-K |
0.5 |
16/0.20 |
0.6 |
2.4 |
|
H05V-K |
0.75 |
24/0.20 |
0.6 |
2.8 |
|
H05V-K |
1 |
32/0.20 |
0.6 |
3.0 |
|
H07V-K |
1.5 |
30/0.25 |
0.7 |
3.5 |
|
H07V-K |
2.5 |
50/0.25 |
0.8 |
4.2 |
|
H07V-K |
4 |
56/0.30 |
0.8 |
4.8 |
|
H07V-K |
6 |
84/0.30 |
0.8 |
6.3 |
|
H07V-K |
10 |
80/0.40 |
1.0 |
7.6 |
|
H07V-K |
16 |
128/0.40 |
1.0 |
8.8 |
|
H07V-K |
25 |
200/0.40 |
1.2 |
11.0 |
|
H07V-K |
35 |
280/0.40 |
1.2 |
12.5 |
|
H07V-K |
50 |
400/0.40 |
1.4 |
14.5 |
|
H07V-K |
70 |
356/0.50 |
1.4 |
17.0 |
|
H07V-K |
95 |
485/0.50 |
1.6 |
19.0 |
|
H07V-K |
120 |
614/0.50 |
1.6 |
21.0 |
|
H07V-K |
150 |
766/0.50 |
1.8 |
23.5 |
Quality Assurance & Certifications
Our production is managed under a strict quality control system to ensure the reliability of each RV Cable:
- Raw material inspection to guarantee conductor and insulation quality
- Electrical performance tests including conductor resistance and insulation integrity
- Flame retardancy and mechanical durability checks
- Certified to CE, RoHS, ISO 9001, IEC 60227-5
Packaging & Shipping
To ensure safe delivery, our RV Cables are packed according to international export standards:
- Coiled in plastic reels, paper spools, or wooden drums
- Wrapped in moisture-proof protective film
- Custom labeling and barcode options available
- Worldwide shipping by sea, air, or express services
After-Sales Service
- Warranty Coverage – 12-month warranty for manufacturing defects
- Technical Assistance – Installation guidance and troubleshooting support
- Rapid Response – All inquiries handled within 24 hours
- Spare Cable Supply – Additional lengths or replacements available on request
- OEM/ODM Service – Full customization for branding and specifications
